Thermal Camera Specifications

Specifications – Indoor Camera

Material	Zinc Alloy
Size	232x88x25mm
Weight	0.5kg
Display	5.5-inch IPS HD Touchscreen
Identification Speed	<0.6s
Voltage	DC12V/2A (DC9V-14V)
Operating Temperature	-10oC to 60oC
Temperature Accuracy	99.9% (+/-0.2oC)
Object Temperature*	36oC to 42oC
Additional Connections	Weigand Input/Output

*Damstra Thermal Camera is purpose-built for detecting human temperatures. Once a face is in frame temperature detection will begin.

Specifications – Outdoor Camera

Material	Zinc Alloy
Size	565x100x155mm
Weight	1.8kg
Display	5.5-inch IPS HD Screen
Identification Speed	<0.6s
Voltage	DC12V/2A (DC9V-14V)
Operating Temperature	-10oC to 60oC
Temperature Accuracy	99.9% (+/-0.2oC)
Object Temperature*	36oC to 42oC
Additional Connections	Weigand Input/Output

*Damstra Thermal Camera is purpose-built for detecting human temperatures. Once a face is in frame temperature detection will begin.
