Indoor Thermal Camera Replacement Guide

Step 1
Turn the base plate over & un-screw the 3x feet from the bottom.

Step 2

Un-screw the lock nut from the base of the pole & remove the old camera (still mounted to the original pole).
Push the new pole (with the new camera attached) through the circular hole. Screw the lock nut onto the pole.


Step 3

Pull the internal cables through the pole.
Connect the internal ethernet cable (highlighted in blue) and the internal power cable (highlighted in orange).


Step 4

Turn the unit over & connect the ethernet and the power cable to the outside of the base.
